A fully automatic project petroleum jelly bottle filling machine line is a highly efficient production system that can automate the entire process of filling, capping, and labeling of petroleum jelly bottles. It is a robust and reliable system designed to handle high volume production, which makes it ideal for large-scale manufacturing companies.

The process of bottle filling begins with the empty bottles being loaded onto the machine line, which is equipped with a conveyor belt to carry them through the various stages of the production process. The bottles are then cleaned, sanitized, and dried to ensure that they are free from contaminants and ready for filling.

Next, the machine line fills the bottles with the desired quantity of petroleum jelly using a high-precision filling system. This system can accurately dispense the product into each bottle, ensuring consistent fill levels and minimizing waste. The bottles are then sealed with caps, which are also automatically placed onto the bottles by the machine line.

After the filling and capping process is complete, the bottles are labeled with product information, such as the brand name, ingredients, and expiration date. The labeling process is also fully automated and can be customized to suit the specific requirements of the manufacturer.

One of the key advantages of a fully automatic project petroleum jelly bottle filling machine line is its ability to operate continuously without the need for human intervention. This means that the system can work around the clock, maximizing productivity and reducing labor costs.

Another benefit of this production system is its ability to minimize product waste and contamination. The machine line is designed to handle the product with care, ensuring that it is not exposed to air or other contaminants during the filling and capping process. This results in a high-quality product that is consistent in texture, color, and fragrance.

In conclusion, a fully automatic project petroleum jelly bottle filling machine line is an excellent investment for manufacturers looking to streamline their production process, increase efficiency, and improve the quality of their products. With its high level of automation and precision, this system can help companies stay competitive in the market while also reducing their operating costs.

Application:

It is suitable for the quantitative filling of various oils such as petroleum jelly, vaseline, face cream, ketchup, tomato sauce, mayonnaise, jam, paste, oil, yogurt, cream, hot sauce, chili sauce, honey, etc.

Packaging Type:

Bottles, Jars, Cans, Tins, Barrel, Capsule, Cartons

Packaging Material:

Glass, Metal, Paper, Plastic, Wood, and Others.

Kindly Reminder:

Fully Automatic Project Petroleum Jelly Bottle Filling Machine Line



ModelVK-ALF01
Filling Range50-1000ml
Filling Speed20-35 bottles/min
Measurement Accuracy±1%
Power220V, 50Hz, 1KW
Working Pressure0.6mpa-0.8mpa
Weight400kg
SizeL4004*W1175.97*H2045(mm)

1. According to the needs of different configurations of automatic equipment assembly;

2. All the machine structures are selected and designed according to the food hygiene standards;

3. The inner wall of the container in contact with the material is polished;

4. The structures that are often disassembled and washed are all connected by easily disassembled parts, which is convenient for cleaning;

5. The packing line is mainly suitable for packing all kinds of liquid, fluid, and paste material, such as juice, edible oil, sauce, daily necessities, medicine, etc;

6. Complete set, the whole line is fully automatic, saving labor;

7. 4 head negative ion bottle washing machine, clean the bottle, keep clean and sanitary;

8. Double-side labeling machine can stick round bottle, single side, double side;

9. The cap sleeve of the bottle is contracted to prevent theft and avoid air entry, which is suitable for preservation;

10. Docking box sealing machine, the whole line is fully automatic, improve output.
