The automatic 6 heads pistons mayonnaise bottle filling machine line is a highly efficient and automated system designed to fill mayonnaise bottles with ease and precision. The system is capable of filling up to six bottles simultaneously, ensuring high-speed production for large-scale mayonnaise manufacturing plants.

The filling machine line consists of several components, including a conveyor system, a piston filling machine, and a capping machine. The conveyor system is responsible for transporting empty bottles from the beginning of the line to the filling station. Once at the filling station, the bottles are held in place by the piston filling machine, which uses six separate pistons to dispense the exact amount of mayonnaise into each bottle.

The piston filling machine operates using a pneumatic system, which is controlled by a programmable logic controller (PLC). This system allows for precise and consistent filling, ensuring that each bottle is filled to the exact same level. The PLC also allows for easy adjustments to be made to the filling volumes, ensuring that the machine can be used for different bottle sizes and filling requirements.

Once the bottles are filled, they are transported to the capping machine via the conveyor system. The capping machine uses a screw-on cap to seal the bottles, completing the filling process. The entire system is designed to be highly efficient, with minimal downtime and maximum throughput.

The automatic 6 heads pistons mayonnaise bottle filling machine line is ideal for large-scale manufacturing plants that require high-speed and accurate filling of mayonnaise bottles. The system is easy to use and maintain, with all components easily accessible for cleaning and maintenance. Overall, this machine line is a reliable and cost-effective solution for businesses looking to improve their mayonnaise production process.

Application:

It is suitable for the quantitative filling of various oils such as mayonnaise, ketchup, oil, yogurt, cream, tomato sauce, hot sauce, chili sauce, honey, etc.

Packaging Material:

Glass, Metal, Paper, Plastic, Wood, and Others.

Kindly Reminder:

Automatic 6 Heads Pistons Mayonnaise Bottle Filling Machine Line



ModelVK-ALF01
Filling Range50-1000ml
Filling Speed20-35 bottles/min
Measurement Accuracy±1%
Power220V, 50Hz, 1KW
Working Pressure0.6mpa-0.8mpa
Weight400kg
SizeL4004*W1175.97*H2045(mm)

1. According to the needs of different configurations of automatic equipment assembly;

2. All the machine structures are selected and designed according to the food hygiene standards;

3. The inner wall of the container in contact with the material is polished;

4. The structures that are often disassembled and washed are all connected by easily disassembled parts, which is convenient for cleaning;

5. The packing line is mainly suitable for packing all kinds of liquid, fluid, and paste material, such as juice, edible oil, sauce, daily necessities, medicine, etc;

6. Complete set, the whole line is fully automatic, saving labor;

7. Piston-type measuring cylinder, servo drive, suitable for large particles of thick sauce filling;

8. Double-side labeling machine can stick round bottle, single side, double side;

9. Special sauce anti-drip filling head and increase the rotary valve, filling large particles of sauce, not blocking and leaking;

10. Horizontal mixing and horizontal pushing design, improve the filling speed, but also solve the problem of the uneven oil layer.
