This machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement. PLC controller and color touch screen are applied and made it possible for programmable control of the machine. It can perform the filling for ointment, cream jellies or viscosity material, tail folding, batch number embossing (include manufacture date) automatically. It’s ideal equipment for plastic tube and laminated tube filling and sealing for cosmetic, pharmacy, foodstuff and bond industries.

Application:

Scope of application: Suitable for packaging in medicine, daily chemical, food, chemical, cosmetics, and other industries, such as ointment, shampoo, adhesive, AB glue, epoxy glue, skin cream, hair dye, shoe polish, toothpaste, and other liquid or paste materials Filling and sealing.

Filling container: plastic tube; composite tube.

Optional supporting devices: Three-dimensional packaging machine, cartooning machine, sealing and cutting machine, heat shrinking machine, etc.

Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Packing Samples:

Automatic Soft Tube Filling And Sealing Machine

ModelVK-TFS-009H
Yield20-40 pcs/min
Pipe diameterΦ10mm-Φ50mm(customizable)
Tube height20mm-250mm(customizable)
Control systemPLC
Power supply220V、50Hz
Airconsumption0.3m³/min
Dimension2180mm*930mm*1870mm(L*W*H)
Equipment Material304
Weight700KG

1. The machine adopts a fully enclosed dust cover, the body is made of SUS304 material, and the appearance is unique and beautiful;

2. The replacement base can be used for filling and sealing various specifications of pipes, the sealing appearance is neat and tidy, and the sealing is firm;

3. Photoelectric benchmarking workstation, with high-precision probes, stepping motors, and other control patterns in the correct position;

4. The filling speed and measurement accuracy are easily adjustable, with high adjustment accuracy and good stability;

5. The machine can be equipped with various filling methods of different specifications to meet the filling requirements of different viscosities;

6. The internal heating is heated by Leister hot air gun, while the external water cooling device is configured to cool down, making the sealing more beautiful;

7. The code typing workstation automatically prints the word code on the position required by the process;

8. All parts of the machine contacting materials are made of stainless steel SUS304;

9. Adopt a PLC control system, with a simple operation, intuitive and convenient, complete functions, and stable operation.

In the bustling world of manufacturing and packaging, efficiency and precision are paramount. And when it comes to packaging products in soft tubes, the need for reliability and speed becomes even more pronounced. That’s where our Automatic Soft Tube Filling and Sealing Machine steps in, revolutionizing your packaging process with its advanced technology and seamless operation.

Designed with cutting-edge features and built to meet the highest industry standards, our machine offers a comprehensive solution for filling and sealing soft tubes with unparalleled efficiency. Whether you’re in the cosmetics, pharmaceuticals, or food industry, this versatile machine is the perfect addition to your production line.

One of the standout features of our Automatic Soft Tube Filling and Sealing Machine is its intuitive interface, which allows for easy operation and minimal training requirements. With user-friendly controls and customizable settings, you can adjust the machine to meet your specific packaging needs with precision and ease.

But it’s not just about ease of use – our machine is also engineered for exceptional performance. Thanks to its high-speed filling and sealing capabilities, you can significantly increase your production output without compromising on quality. Say goodbye to bottlenecks and hello to streamlined packaging processes.

Furthermore, our Automatic Soft Tube Filling and Sealing Machine is equipped with advanced safety features to ensure peace of mind during operation. From automatic error detection to emergency stop mechanisms, we’ve prioritized safety every step of the way.

Moreover, versatility is at the core of our machine’s design. Whether you’re filling and sealing tubes of varying sizes, shapes, or materials, our machine can handle it all with precision and consistency. With adjustable settings and interchangeable parts, you can adapt the machine to accommodate a wide range of packaging requirements.

In addition to its performance and versatility, our Automatic Soft Tube Filling and Sealing Machine is also designed with durability in mind. Constructed from high-quality materials and engineered to withstand the rigors of continuous operation, you can count on this machine to deliver reliable performance day in and day out.

But perhaps most importantly, investing in our Automatic Soft Tube Filling and Sealing Machine is an investment in the future of your business. By streamlining your packaging processes, reducing downtime, and increasing efficiency, you can not only save time and money but also gain a competitive edge in today’s fast-paced market.

In conclusion, our Automatic Soft Tube Filling and Sealing Machine is more than just a piece of equipment – it’s a game-changer for your packaging operations. With its advanced features, intuitive design, and exceptional performance, this machine is the key to unlocking new levels of efficiency and productivity in your business. Experience the difference for yourself and elevate your packaging process to new heights with our cutting-edge machine.
